Universal Lathe Machine CQ6236
Universal Lathe Machine CQ6236
Technical parameters:
| universal metal working lathe machine | |||
| Model | CQ6236 | ||
| Max.swing over bed | Φ360mm | ||
| Max.swing over cross slide | Φ212mm | ||
| Max. swing over gap | Φ491mm | ||
| Distance between centers | 750mm/1000mm | ||
| Spindle bore | Φ38mm / 52mm | ||
| Taper of spindle bore | M.T.#5 | ||
| Range of spindle speeds | 70~2000rpm | ||
| Taper of tailstock | M.T.#3 | ||
Range of metric threads | 0.4-7mm | ||
Range of inch threads | 4-60 T.P.I. | ||
| Range of longitudinal feeds | 0.052~1.392mm/rev. | ||
| Range of cross feeds | 0.018~0.238mm/rev. | ||
Unitary packing size | 1940×760×1520mm | ||
Asunder packing size | 1950×750×770mm | ||
Left stand packing size | 690×420×440 | ||
Right stand packing size | 690×420×320 | ||
| Motor power | 1.5KW | ||
Lathe Machine Accessories:
| Standard accessories： | Optional accessories： |
| ·3 Jaw chuck(Φ160mm) | ·4 Jaw chuck(Φ200mm) |
| ·Change Gears Set | ·Face Plate |
| ·M.T.#3 Dead Centers | ·Steady Rest |
| ·M.T.#5/3 Reduction Sleeve | ·Follow Rest |
| ·Oil gun | ·Work Light |
| ·Splash Guard | ·Foot Brake System |
| ·Foot stands | ·Coolant System |
| ·Tool Box&Tools | ·Live Center |
| ·Oil Tray | ·Drill Chuck+Drill Arbor |
| ·Leadscrew Guard | |
| ·Chuck Guard | |
| ·Localizer | |
| ·Clutch For Feed Rod | |
| ·Quick Change Tool Post | |
| ·Digital Readout(2 Axis) |
